Anchor Advance FR 4 sq mm Green 90 m FR PVC Insulated Wire

(0) Review

₹7,114

Brand Anchor ISIN EDLEQNIOXA Offer ID 1000350583 Brand Collection Name Advance FR Brand Model Number 27426 Size 4 sq mm Brand Colour Green Length 90 m Voltage 1100 V Rated Current 29 A Conductor Type Stranded Conductor Material Copper Insulated Material FR PVC Core 1 Core Certification IS: 694 Usage Residential Pack Of 1 Warranty Not Applicable Country of Origin India

Available Options Color

Category :Electricals

Sub Category :Wires & Cables

Stock : 8

Anchor introduces Advance FR (Flame Retardant) wire confirming to IS 694, 1100V (1.1 KV) with specially formulated proprietory PVC compound. Key Features: Exceptional flame retarding properties to the insulation Higher oxygen index (LOI) of 30% and temperature index of 3000C against specified category C1 values of 29% and 2500C respectively

Flame Retardant (FR) PVC Insulation – Specially formulated PVC insulation helps prevent the spread of fire and improves electrical safety.
High Oxygen Index (~30%) – Offers superior flame resistance compared to ordinary PVC wires.
High Temperature Index (~300°C) – Designed to withstand higher temperatures for safer operation.
High Insulation Resistance (HIR) – Minimizes leakage current and improves electrical safety
Suitable for Residential & Commercial Wiring – Ideal for homes, offices, and electrical installations up to 1100 V.

Brand:	Anchor
Wire Type	: Advance FR (Flame Retardant) PVC Insulated Building Wire
Length:	90 meters
CopperConductor Material:	100% Electrolytic Grade
Conductor Type:	Single core, multi-strand copper
Strand Diameter:	0.3 mm
Voltage Rating	1100 V (1.1 kV)
Current Rating:	Approx. 29 A
Temperature Index	Up to 300°C
